Selected reference: MGT001- Configuration
- 2 switches · 2M
- Plate format
- 2M (M = Gang)
- 23A heavy-duty switches
- 0
- 10A normal relays
- 2
- 100W fan dimmers · conventional fans only, not BLDC
- 0
- Two-way controls
- Not available
- Sockets
- 0
- Production status
- In production
- Supply
- 230V AC · 50/60Hz
- Front panel
- Capacitive touch · tempered glass
- Finishes
- White · Black · Grey
- Status indication
- RGB LED indication
- Touch operation rating
- More than 100,000 operations
- Standard switching channel
- 10A relay; load limits depend on appliance type
- Operating temperature
- 0°C to 45°C
- Operating humidity
- 5%–90% RH · non-condensing
- Firmware
- Over-the-air updates
- Warranty
- 5-year service warranty for magnetic TouchX panels
Icon layout and circuit suitability are confirmed for your chosen configuration. See the TouchX technical guide for load limits and installation requirements. Heavy-duty control requires a model with a dedicated HD channel.
